Acoustic partition walls
GEZE Slifold 100 * Manual partition wall system with a panel height of up to 12 m and a max. sound insulation of Rw=58 dB(A)
- The horizontal sealing profiles are operated manually and semi-automatically
- Panels are moved manually in the track
- Panel design: MDF board finish, max. 3.5 m panel height and max. Rw=44 dB(A)
- Panel thickness is 100 mm
- Anodised ceiling track with sealing-off corresponding to the sound insulation value
- Vertical profiles of the panels are made of aluminium, anodised finish
- No floor guides necessary
- Stacking area possible inside and outside the partition wall axis
- High-quality track system
- Optionally available with single and double leaf sliding swing doors
- Magnetic vertical seals are included
Application Areas
- Individual space solutions
- Building-specific partition wall solutions
- Innovative space concepts
- Moveable acoustic partition walls
- Inside
Installation situations in reference objects and videos
GEZE Slifold 100
© GEZE GmbH
Technical data
| GEZE Slifold 100 | |
| Frameless | No |
| Indoor use | Yes |
| Outdoor use | No |
| Leaf width (min.) | 600 mm |
| Leaf width (max.) | 1220 mm |
| MDF board thickness | 16 - 18 mm |
| Stacking area layout | Automatic, Linear, Manual |
| Fully automatic operation | No |
| Manual operation | Yes |
| Semi-automated operation | Yes |
| Optional floor guide | No |
| Top and bottom sealing brushes | Yes |
| Retractable seal | Yes |
Downloads
GEZE Slifold 100
LABELLING OBLIGATION: © GEZE GmbH
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
